OUTPUT
Frequency compatibility
Output watts
Output nominal voltage
Output voltage regulation
Output frequency regulation
Overload protection
Outlet quantity / type
60 Hz
Continuous - 600 watts, Overpower (up to 1 hour) - 900 watts, Double-Boost wattage (up to 10 seconds) - 1200
watts
AC OUTPUT: 120V AC nominal, DC CHARGER OUTPUT (DC): 12V DC nominal
LINE POWER (AC): Maintains 120V nominal sine wave output. INVERTER POWER (AC): Maintains PWM sine
wave output voltage of 120 V AC (+/-5%). DC CHARGER OUTPUT (See battery recharge rate section)
60 Hz (+/- 0.3 Hz)
Includes 6A input breaker dedicated to the charging system and 6A output breaker for AC output loads
Includes 2 AC outlets (NEMA 5-15R)
INPUT
DC INPUT: Requires 12V DC input source capable of delivering 56A for the required duration (when used at full
Recommended Electrical Service
Maximum input amps / watts
Input connection type
Voltage compatibility (VAC)
Voltage compatibility (VDC)
BATTERY
Expandable battery runtime
DC system voltage (VDC)
Battery Pack Accessory (optional)
Battery charge
continuous capacity). For automotive applications, professional hardwire installation with 100A minimum battery
system fusing is recommended.
DC INPUT: Full continuous load - 56A at 12V DC. AC INPUT: 9.2 amps at 120VAC with full inverter and charger
load
DC INPUT: Set of 2 DC bolt-down terminals. AC INPUT: NEMA 5-15P input plug
120
12
Runtime is expandable with any number of user supplied wet or gel type batteries
15
98-121 sealed lead acid battery (optional)
Includes 20 amp DC charging system with selectable profiles for vented wet cell and sealed gel cell batteries (see
manual for detailed charger information)
LEDS ALARMS & SWITCHES
3 position on/off/remote switch enables simple on/off power control plus "auto/remote" setting that enables distant
Switches
Front panel LEDs
PHYSICAL
Shipping Dimensions (HWD/in)
Shipping Dimensions (HWD/cm)
Shipping weight (lbs)
on/off control of the inverter system when used in conjunction with optional APSRM4 accessory when used in
inverter mode. In AC uninterruptible power mode, "auto/remote" setting enables automatic transfer from line power
to battery power - to maintain continuous AC power to connected loads.
Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7
levels reported). See manual for sequences.
12.5 x 14 x 10.5
31.8 x 35.6 x 26.7
18
2 / 3
